XHF-13 Washing Color Fastness Tester

Product Category:Color Fastness Tester

Share:

Product Description

The Washing Fastness Tester(launder o meter rotawash, dynowash),is used to determine color fastness to washing or dry cleaning to washing fastness methods, it complies with ISO, Next, AATCC and M&S standards.


Test Standards

AATCC61/86/132/151/190,ISO105-C01/C02/C03/C04/C06/C07/C08/C09/C10/D01/E03/E12, BS 1006, M&SC4A/C5/P3B/C10A/C11/C26/C37/C49A/P137, NEXT 2/3/5, IWSTM7/115/177/193/199/240/241, FTMS 191-5610/5622


Product Features

The whole machine is made of thick high-quality stainless steel, advanced CNC laser cutting, CNC molding, more reliable, surface drawing process, beautiful and high-grade.



The machine height is suitable for user’s operation.



The machine all use high-quality stainless steel, and the internal test box is made of SUS304 stainless steel, which is beautiful in appearance and durable


Available in different sizes such as portable washing fastness tester, etc. The washing fastness tester uses stainless steel rotor to holds washpots on each of four sides and rotates at a constant 40 rpm (+/-2 rpm). The stainless steel wash cup made by molding guarantees easy opening and closing, and does not leak when sealed, containers are sealed with either a Neoprene rubber gasket or optional Teflon gasket.





Optimized piping design, high position water inlet, more convenient installation of laboratory piping; Drain and overflow design in parallel, reducing the number of piping, more tidy





The controller adopts an advanced touch screen control system, which further improves the control accuracy and brings a better operating experience. It uses a 260,000 color color HD display touch screen with timely response and clear display. The operating interface adopts the internationally popular flat design for easy operation.



Indication of various states such as water shortage, door limit, heating, test running, test completion, current temperature, running time, etc., and the operating conditions are clear .





8, 12, 20, 24 and other choices’ stations meet the different test needs, customers can choose the number of ISO or AATCC test cups according to the actual test standard usage and demand, the configuration method is more flexible and free.


Technical Parameter

Capacity

8, 12, 16, 20 Capacity

Rotation Speed

40+/-2/rpm

No.of heaters

2 Pcs

ISO Container (A Type)

550ml  75mm dia x 125mm(3.0 in x 5.0in)

AATCC Container (B Type)

1200ml 90mm diax 200mm(3.5 in x 8.0in)

Temperature

Max 95C  Adjustable

Temperature Accuracy

+/-1.0 C

Running Time

Adjustable, timer tells operator when the test will be finished

Power Supply

220V, 50Hz, Single Phrase
