XHF-116 Protective Clothing Leakage Tester
Product Category：Protective Clothing Tester
Protective Clothing Leakage Tester
Samples of chemical protective clothing materials that have either been abraded or flexed are placed on a fixture and are then subjected to a reduced pressure. The resulting pressure is then measured. A comparison is made for the ending pressure between abraded or flexed and pristine samples.
ISO 16602 Annex G
Test Station | 1 Station |
Test Pressure | -1KPa |
Test Time | 1min |
Timing | 0~99min59s adjustable |
Specimen Size | 50mm×105mm |
Specimen Quantity | 3 |
Dimension (WxDxH) | 30×30×30cm |
Weight (Kg) | ≈12Kg |
Power Supply | 1∮ AC 220V 60Hz 2A |
