+86-531-67880131Your Location：Home > PRODUCTS>Fabric and Yarn Testing Equipments>Abrasion Tester
Taber Abrasion Tester is used for cloth, paper, paints, plywood, leather, tile, glass, rubber, etc .The testing method is executed to make specimen abraded by a pair of grinding wheels under the specified load .The weight of abrasion loss is the difference of weight for specimens before and after testing .
DIN53754, 53799, 53109, 52347, TAPPI T476, ASTM D3884, ISO 5470,
ASTM D 1175, ASTM D1044, ISO 7784, ASTM D4060, EN 660-2
It is very convenient to install taber grinding wheel.
Weight Deduction Accessories is available for this machine.
Distance between wheel internal faces | 52.5mm-53.4mm (adjustable) |
Rotating Speed | 60-75r/min (Adjustable) |
Test Load on specimen | 250g, 500g, 1000g |
Distance between nozzle and specimen surface | 1-7mm (adjustable) |
Hole diameter | 6.35mm |
Test times | 0-99999 Autostop and alarm |
Dimensions | 250×310×190mm |
Weight | 11 Kgs |
Power Supply | 220V, 50/60Hz, Single Phase |
Standard Configuration | Machine(include sample holder, hold down ring, power cord, weights, hex wrench, brush),Vacuum Cleaner with Suction CS-17 Calibrase Wheel 1 Pair |
